Power
Transformers

ELSPRO transformers in housings made of high-quality, robust solid rubber are an investment in safe working with Power. The durable ELSPRO solid rubber housings of all product series are manufactured using the press and vulcanization process. The action of heat and pressure makes rubber mechanically resilient and largely resistant to chemical, aging and weathering influences. ELSPRO transformers are available in numerous housing sizes. The assembly and design is carried out according to customer requirements in compliance with the applicable standards and directives.

Safety transformers and isolating transformers according to VDE 0570/DIN EN 61558

to the products

Special features

HOUSING

Housing made of high-quality solid rubber (butyl rubber)
corrosion, oil, acid and alkali resistant
Impact resistant and mechanically highly resilient
Suitable for rough construction sites
UV and ozone resistant
for permanent outdoor use
Shore hardness at least 96° Shore according to DIN 53505
self-extinguishing and flame retardant according to VDE 0471/DIN EN 60695

TRANSFORMER SELECTION

Single-phase transformers or multi-phase transformers
Voltages 12 V to 500 V
Power ratings 120 VA to 4,500 VA
larger transformers on request

PLUG-IN DEVICES

VDE tested and approved
Nickel plated contacts
individually interchangeable
Fastened with ISO through bolts

HEDGING MEASURES PRIMARY

Upstream connection of a thermal overcurrent circuit breaker matched to the primary current
optimal protection of the transformer in case of overload and short circuit
Reliable switching behavior due to snap-action mechanism
uninfluenceable free release
Reset of the switch after rectification of the cause of the fault by pressing a button from the outside

HEDGING MEASURES SECONDARY
